Transmitter
Transmission Type
2.4GHz Digital Frequency
Modulation
GFSK
Operating Range (without obstacle)
Up to 328ft (100m)
RF Output Power
＜10mW
Polar Pattern
Omnidirectional
Frequency Response
50Hz-18KHz
Maximum SPL
Built-in Microphone: 120dB SPL
Lavalier Microphone: 110dB SPL
Sensitivity
Built-in Microphone: -39dB
Lavalier Microphone: -39dB
SNR
> 84dB
Power Requirements
Built-in Li-ion Battery or USB-C DC 5V or Charging Contact
Built-in Battery Life
Approx. 7 hours
Antenna
PIFA Antenna
Audio Inputs
3.5mm TRS MIC/LINE IN Jack or Built-in Microphone
Weight
Approx. 32g(1.13oz)
Dimensions
62.1×31.6×16.5mm
Operating Temperature
–10°C to 50°C
Storage Temperature
–20°C to +55°C
Receiver
Transmission Type
2.4GHz Digital Frequency
Modulation
GFSK
Operating Range (without obstacle)
Up to 328ft (100m)
Audio Output Connector
3.5mm Headphone Jack
3.5mm TRS Output Jack
Audio Output Level
–60 dBV to -20dBV
Power Requirements
Built-in Li-ion Battery or USB-C DC 5V or Charging Contact
Built-in Battery Life
Approx. 6.5 hours
Antenna
PIFA Antenna
Weight
Approx. 32g(1.13oz)
Dimensions
62.1×31.6×16.5mm
Operating Temperature
–10°C to 50°C
Storage Temperature
–20°C to +55°C
