Canon XF605 UHD 4K HDR Pro Camcorder

Canon XF605 Specs

Sensor Resolution	Actual: 13.4 Megapixel (4268 x 3148) Effective: 8.29 Megapixel (3840 x 2160)
Image Sensor	1″-Type CMOS
Image Stabilization	Optical in Integrated Lens Digital
Internal Recording Modes	H.264/MP4 4:2:0 8-Bit 3840 x 2160 from 1 to 23.98/25/29.97/50/59.94 fps [150 Mb/s] 1920 x 1080p from 1 to 23.98/25/29.97/50/59.94 fps [35 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps H.265/MP4 4:2:2 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [135 to 225 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps [12 Mb/s] H.265/MP4 4:2:0 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 170 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps [9 Mb/s] MXF/XF-AVC 4:2:2 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [160 to 410 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 to 310 Mb/s] 1920 x 1080i at 50/59.94 fps [50 to 160 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fpsShow More
External Recording Modes	SDI/BNC UHD 4K (3840 x 2160) up to 59.94 fps
Media/Memory Card Slot	Slot 1: SD/SDHC/SDXC Slot 2: SD/SDHC/SDXC
Video I/O	1x HDMI 2.0 Output 1x BNC (12G-SDI) Output
Battery Type	Canon BP-A Series

Imaging

Sensor Resolution	Actual: 13.4 Megapixel (4268 x 3148) Effective: 8.29 Megapixel (3840 x 2160)
Image Sensor	1″-Type CMOS
Image Stabilization	Optical in Integrated Lens Digital
Built-In ND Filter	Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Capture Type	Stills & Video

Exposure Control

Shutter Type	Electronic Rolling Shutter
Shutter Speed	1/2000 to 1/4 Second
Shutter Angle	11 to 360°
Sensitivity	f/12 at 2000 lux
Minimum Illumination	1.5 Lux at 1/30 Shutter Speed
White Balance	Range: 2000 to 15,000K

Lens

Focal Length	8.3 to 124.5mm (35mm Equivalent: 25.5 to 382.5mm)
Optical Zoom Ratio	15x
Max Digital Zoom	30x ( in 1080p)
Maximum Aperture	f/2.8
Minimum Aperture	f/4.5
Minimum Focus Distance	2′ / 60 cm
Filter Size	58 mm
Control Rings	Focus Zoom Iris
Focus Control	Autofocus Manual Focus

Video Capture

Internal Recording Modes	H.264/MP4 4:2:0 8-Bit 3840 x 2160 from 1 to 23.98/25/29.97/50/59.94 fps [150 Mb/s] 1920 x 1080p from 1 to 23.98/25/29.97/50/59.94 fps [35 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps H.265/MP4 4:2:2 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [135 to 225 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps [12 Mb/s] H.265/MP4 4:2:0 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 170 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps [9 Mb/s] MXF/XF-AVC 4:2:2 10-Bit 3840 x 2160 at 23.98/25/29.97/50/59.94 fps [160 to 410 Mb/s] 1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 to 310 Mb/s] 1920 x 1080i at 50/59.94 fps [50 to 160 Mb/s] 1280 x 720 at 23.98/25/29.97/50/59.94 fps
External Recording Modes	SDI/BNC UHD 4K (3840 x 2160) up to 59.94 fps
Fast-/Slow-Motion Support	Yes
Gamma Curve	Canon Log 3, HDR-HLG
Built-In Microphone	Stereo
Audio Recording	2-Channel 16-Bit 48 kHz AAC Audio 4-Channel 24-Bit 48 kHz LPCM Audio
IP Streaming	MPEG2 1920 x 1080 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 16.0 Mb/s) 1920 x 1080 at 50i, 59.94i (4.0 to 9.0 Mb/s)

Interface

Media/Memory Card Slot	Slot 1: SD/SDHC/SDXC Slot 2: SD/SDHC/SDXC
Video I/O	1x HDMI 2.0 Output 1x BNC (12G-SDI) Output
Audio I/O	2x XLR 3-Pin Input 1x 1/8″ / 3.5 mm TRS Stereo Input 1x 1/8″ / 3.5 mm TRS Stereo Headphone Output
Power I/O	1x Barrel (24VDC) Input
Other I/O	1x USB-A Output 1x USB-C 1x BNC (Genlock, Sync) Input/Output 1x BNC (Timecode) Input/Output 1x 2.5 mm Sub-Mini Control 1x D-Sub 8-Pin Control 1x RJ45 (LAN) Input/Output
Wireless	2.4 / 5 GHz MIMO Wi-Fi Video Output, Audio Output, Control
Global Positioning (GPS, GLONASS, etc.)	No

Monitor

Display Type	Primary Monitor: Articulating 3.5″ Touchscreen LCD
Resolution	Primary Monitor: 2,760,000 Dot

Viewfinder

Type	Removable Electronic (OLED)
Resolution	1,770,000 Dot

Focus

Focus Mode

Automatic, Manual Focus

Power

Battery Type	Canon BP-A Series
Power Consumption	21.5 W

Environmental

Operating Conditions

32 to 104°F / 0 to 40°C up to 85% Humidity

General

Shoe Mount	1x Intelligent Hot Shoe 1x Cold Shoe
Tripod Mounting Thread	1/4″-20 Female 3/8″-16 Female
Built-In Video Light	Yes (Infrared)
Dimensions (W x H x D)	15.2 x 8.6 x 8.3″ / 385 x 219 x 210 mm (With Protrusions) 13.1 x 6.8 x 6.6″ / 333 x 173 x 168 mm (Without Protrusions)
Weight	4.4 lb / 2010 g (Body Only)

Packaging Info

Package Weight	10.98 lb
Box Dimensions (LxWxH)	17 x 14.4 x 11.5″
